LC107-10
10 lbf, ± 0.10%, Linearity, 2 mV/V Output, Cable
Volume discounts available
Volume Discount Schedule
| Quantity | Price each |
|---|---|
| 1-9 | $642.13 |
| 10-24 | $610.02 |
| 25-49 | $597.18 |
| 50-99 | $577.92 |
| 100+ | $558.65 |
Added to Your Shopping Cart
Configuration complete.
Please add to cart to keep it or exit the configuration
Please add to cart to keep it or exit the configuration
Failed to Save Configurations, Click on Configure Button Start Again
Product Specs
<< See all Product Models| Brand |
 |
| 5-Point Calibration | 0%, 50%, 100%, 50%, 0% |
| Cable Length | 5 ft |
| Calibration Option | 5 POINT NIST |
| Electrical Connection | Cable |
| Electrical Output | 2 mV/V |
| Enclosure Ratings | IP40 |
| Force Type | Compression, Tension |
| Height | 1.25 in |
| Hysteresis | ± 0.1% |
| Length | 1.1 in |
| Linearity | ± 0.1% |
| Load Cell Capacity | 10 lbF |
| Load Cell Type | S-beam |
| Materials | Stainless Steel, Aluminum |
| Operating Temperature, Max | 93 °C |
| Operating Temperature, Min | -40 °C |
| Overload, Max | 300% FS |
| Process Temperature, Max | 71 °C |
| Process Temperature, Min | 15 °C |
| Repeatability | ± 0.05% |
| Safe Overload | 150% FS |
| Supply Power Note | 5 Vdc Nominal, 15 Vdc Maximum to 5 Vdc Nominal, 12 Vdc Maximum |
| Supply Voltage | 5 Vdc |
| Thermal Span Effect | ± 0.009% FSO/°C |
| Thermal Zero Effect | ± 0.009% FSO/°C |
| Width | 0.5 in |
| Zero/Balance Error | ± 1% |
| See All Specs | |
